FEATURES
MELF Glass encapsulated precision NTC thermistor are the latest NTC thermistor developed by EXSENSE Electronics. It meets the requirements of RoHS and is suitable for electric rice cookers, microwave ovens, induction cookers, coffee pots, etc.
1. SizeΦ3.6mm*1.6mm
2. Resistance range: 1KΩ~2MΩ
3. B Value: 2000~6000K
4. Operating Temperature Range-40～+250℃
5. Compliance with requirements of RoHS
2. Resistance range: 1KΩ~2MΩ
3. B Value: 2000~6000K
4. Operating Temperature Range-40～+250℃
5. Compliance with requirements of RoHS
APPLICATION
Electric rice cookers, microwave ovens, induction cookers, coffee pots, etc.
Part Number Identification
Electronic Parameter Specification
Resistance Value: R25=5KΩ±5%
B Value: B25/50=3375K±5％
Thermal time constant: ≤20s (In still air)
Dissipation Factor: ≤2.5mW/℃ (In still air)
Operating temperature range: -40~+250℃
Package
